| BIG.SEVEN TFS III, material: aluminium 27.5x2.25" max. wheelsize 135x9mm axle standard BSA bottom bracket standard |
|
| 27.5 |
|
| Rock Shox Judy TK, Coil 100mm suspension travel Lockout 42mm fork offset 27.5x2.25" max. wheelsize |
|
| Shimano ST-EF505 |
|
| Shimano ST-EF505-2L |
|
| Shimano FD-M2020-TS [2s] |
|
| Shimano RD-M370 |
|
| MERIDA M2345 |
|
| MERIDA CC, material: aluminium 31.8mm diameter 6° stem angle 70 mm-XS/S, 80 mm-M, 90 mm-L |
|
| MERIDA CC, material: aluminium 690mm width 15mm rise |
|
| MERIDA EC |
|
| Shimano ST-EF505 |
|
| Shimano ST-EF505 |
|
| Shimano MT101-2, 36-22 teeth 170 mm-XS/S, 175 mm-M/L |
|
| Shimano BB-UN100 |
|
| Shimano CS-HG200, 11-32 teeth 9 speed |
|
| KMC M99 |
|
| VP VPE-891 |
|
| MERIDA CC, 17mm inner width material: aluminium |
|
| MERIDA K1080, 27.5x2.2" wire |
|
| Shimano TX505, 100x9mm width front hub 32 spoke holes Centerlock |
|
| Shimano TX505, 135x9mm width rear hub 32 spoke holes Centerlock |
|
| MERIDA Sport comfort |
|
| MERIDA CC, material: aluminium 30.9mm diameter 15mm setback |
|
| 18 |
|
